CSA Loops

Hose:

 316SS Corrugated Hose, 304SS Single Braid

Elbows:

Carbon Steel, Sch 40

Ends:

Carbon Steel Sch40 Male NPT

CSA Loops
Size (In.) Overall Length OAL (In.) Part Numbers H (In.) Pressure Ratings (PSI) Allowable Motions Z, Y or Z
1/2 28-1/2 CSA-EVT-40050 10-1/2 150 @ 70° F 4"
3/4 30-3/4 CSA-EVW-40075 12 150 @ 70° F
1 33-3/4 CSA-EVW-40100 13 150 @ 70° F
1-1/4 37 CSA-EVW-40125 14-1/2 150 @ 70° F
1-1/2 41 CSA-EVW-40150 16-1/2 150 @ 70° F
2 45-1/2 CSA-EVW-40200 18-1/2 150 @ 70° F
2-1/2 45-1/2 CSA-EVW-40200 18-1/2 150 @ 70° F
3 57-1/2 CSA-EVW-40300 23-3/4 150 @ 70° F
4 62-1/2 CSA-EVW-40400 26 150 @ 70° F
CSA Loops
Size (In.) Overall Length OAL (In.) Part Numbers H (In.) Pressure Ratings (PSI) Allowable Motions Z, Y or Z
1/2 28-1/2 CSA-EVW-40050 10-1/2 150 @ 70° F 4"
3/4 30-3/4 CSA-EVW-40075 12 150 @ 70° F
1 33-3/4 CSA-EVW-40100 13 150 @ 70° F
1-1/4 37 CSA-EVW-40125 14-1/2 150 @ 70° F
1-1/2 41 CSA-EVW-40150 16-1/2 150 @ 70° F
2 45-1/2 CSA-EVW-40200 18-1/2 150 @ 70° F
2-1/2 45-1/2 CSA-EVW-40200 18-1/2 150 @ 70° F
3 57-1/2 CSA-EVW-40300 23-3/4 150 @ 70° F
4 62-1/2 CSA-EVW-40400 26 150 @ 70° F

CSA Loops

EFP CSA rated loops are designed specifically for natural gas piping applications and are certified by CSA International for applications in the United States and Canada.

These loops are constructed with 316SS hose & 304SS braid, either carbon steel or stainless steel Sch40 elbows and either male NPT or beveled pipe ends. These CSA rated loops are rated for 150 psig with a minimum of 6:1 safety factor.

EFP CSA rated loops are all rated for 4” travel (motions X, Y or Z) and are available in 1/2” through 4” diameter.
